Rendering Applying the wound-core principle to a dry-type unit lowers both no-load loss and the acoustic signature — the two parameters that most often decide whether a dry-type transformer can be placed next to occupied space. Suited to apartment buildings, hospitals and mixed-use developments.
| Model / Series | SCB10-RL-30~2000/10 |
|---|---|
| Rated Capacity | 30 – 2000 kVA |
| Voltage Level | 10 kV / 0.4 kV |
| Um (IEC 60071-1) | 12 kV |
| Phase | Three-phase |
| Cooling Method | AN / AF |
| Executive Standard | IEC 60076-11 |
Tell us capacity, voltage and quantity — pricing within 12 hours.
